ARNOTT Ultimate Ride Adjustable Air Suspension Shock Absorbers w/Adjustable Rebound – MC-2909

Arnott Ultimate Ride Adjustable Air Suspension Shock Absorbers w/Adjustable Rebound – MC-2909

The stylish new chrome, rebound-adjustable FOX® Air Suspension System from Arnott has been custom designed for Harley Davidson® models to give the rider superior control, additional ride comfort settings and fast ride height adjustability. The FOX shock’s custom valving, designed for your motorcycle, provides you with a safe and comfortable ride. Arnott’s patent pending kit offers TruAIR technology with a rugged air spring bladder and shock damper design, not an air cylinder or air assisted unit. For added ride comfort, this kit includes FOX’s adjustable rebound control dial so you can quickly and easily adjust your shock’s internal damping characteristics – a feature not found elsewhere in the air suspension market.

At the core of this system are two chrome custom gas pressure FOX shock absorbers with rebound control knobs (optional); then using a patent pending design, Arnott adds a rugged Goodyear® air spring to each, ensuring superior comfort, ride quality and durability. Arnott pairs your shocks with a small, but powerful, compressor, application-specific mounting bracket and air distribution valve block, which includes a muffler to control how fast air is released. Each kit includes everything you need for a fast and flawless installation, including a detailed installation manual, a fused wiring harness and relay assembly, handlebar-mounted inflation switch, all necessary tubing, wiring, cable ties, fittings, chrome bolt covers and mounting accessories. Each shock is custom-crafted and rigorously tested in Arnott’s Florida manufacturing facility.

Features:

Chrome or Black FOX shock absorbers

Adjustable rebound control (optional)

Goodyear air spring sleeves

Compressor with vent solenoid

6061-T6 billet aluminum construction

Handlebar-mounted inflation switch

Engineered for touring series motorcycles

Even deflated fender won’t touch tires

Made and tested in USA

Included Items:

(2) Black shock assembly

(1) Compressor assembly

(1) Chrome compressor cover

(1) 4mm Nylon tubing

(1) 3′ Split loom hose

(1) Micro relay assembly

(1) Wire harness

(2) Ring terminals

(4) Female spade connectors

(4) Male spade connectors

(1) Universal fuse holder with wiring harness

(3) Fittings

(2) Sleeves

(2) 6mm-1.00 x 50mm Socket head bolts

(2) 6mm-1.00 x 18mm Socket head bolts

(2) 6mm-1.00 x 20mm Button head bolts

(4) 6mm Flat washers

(1) Handlebar switch with wiring harness

(8) Cable ties

(2) Male spade connectors

(1) Female spade connector

(8) 7-1/2″ Cable ties

Instructions

Specifications

Mfg #: MC-2909

Part #: 586322

Type Shock Absorber

Units Pair

Weight 21.20 lbs
